Ultra-high-molecular-weight polyethylene (UHMW-PE) is the go-to polymer when moving parts must survive 10 million+ sliding cycles while shrugging off chemicals, water and extreme abrasion. Once limited to compression-molded sheets and CNC machining, UHMW-PE is now injection-moldable—unlocking complex geometries, tighter tolerances and lower part cost for bearings, conveyor flights and wear plates. Here’s how to design and process UHMW-PE for industrial success—and how TaiwanMoldMaker.com fast-tracks every step.
1 Why UHMW-PE Beats Conventional Wear Materials
Property | UHMW-PE | POM (Acetal) | Nylon 6/6 | PTFE-Filled Bronze |
---|---|---|---|---|
Abrasion index (lower = better) | 100 | 180 | 250 | 220 |
Static friction vs. steel | 0.14 | 0.35 | 0.40 | 0.32 |
Water absorption (24 h, %) | < 0.01 | 0.25 | 1.5 | — |
Impact strength (kJ/m²) | No break | 8 | 6 | – |
Density (g/cm³) | 0.93 | 1.41 | 1.14 | 7.8 |
Key takeaway: UHMW-PE out-wears acetal and nylon by 3-10× while weighing a fraction of bronze or steel.
2 Processing Challenges—and Proven Solutions
Issue | Cause | Solution (TaiwanMoldMaker.com Standard) |
---|---|---|
High melt viscosity | MW = 3–6 million g/mol | Extended-stroke screws (28–30 L/D) and low-shear barrier flights |
Poor flow length | Resin chains entangle | Hot runners at 220 °C + mold temp 100–120 °C to keep melt mobile |
Shrink & warp | High crystallinity | Uniform wall ≤ 8 mm; balanced gates and conformal cooling |
Delamination at weld lines | Incomplete knit | Valve-gate sequencing and melt front simulation in Moldflow® |
UHMW-PE can be physically foamed (N₂) to drop weight 8-12 % without sacrificing wear life—useful for large pulleys and liners.
3 Design Guidelines for Long-Life Parts
-
Wall Thickness: 4–8 mm; thicker walls risk sink and cooling stress.
-
Radii & Fillets: ≥ 0.6× wall to avoid notch failure.
-
Draft: 1.5–2° per side; UHMW-PE grips steel harder than PP or HDPE.
-
Interference Fits: Ø −0.05 mm/25 mm for press-fit on 20 °C parts—material cold-flows slightly during service.
-
Lubricant Grooves: Mold-in shallow chevrons; UHMW-PE is self-lubricating, but grooves aid dirt purge.
4 High-Wear Industrial Applications
Segment | Injection-Molded UHMW-PE Parts |
---|---|
Bulk-Handling & Mining | Flight bars, bucket liners, chute blocks |
Food & Bottling | Conveyor wear strips, star wheels (FDA grades) |
Packaging Machinery | Chain guides, quiet cam followers |
Agriculture | Seed drill bearings, scraper blades |
Maritime & Offshore | Fender pads, winch bushings (salt-water inert) |
UHMW-PE grades are available with UV stabiliser, static-dissipative carbon or glass micro-fibres for added stiffness.
5 TaiwanMoldMaker.com Capabilities for UHMW-PE
Capability | Benefit to Your Program |
---|---|
350 t electric presses with 30 L/D screws | Handles UHMW melt without overheating |
Valve-gate hot-runner design in-house | Clean gate vestige on Class-A surfaces |
Moldflow® knit & warp simulation | Eliminates trial-and-error iterations |
ISO 9001 & IATF 16949 plants | Automotive & heavy-equipment compliance |
48-Hour UHMW DFM Pack | Gate plan, cooling layout, cost/timeline ladder |
Bridge-tool credits: up to 50 % of aluminium tooling cost rolls into multi-cavity H13 steel once volumes scale.
6 Quick Engagement Roadmap
-
Upload your CAD + wear-life targets (cycles, load, speed).
-
Receive a 48-hour UHMW DFM & quote—includes part & tool price, cycle-time model.
-
Approve aluminium pilot tool → get T-0 parts in 15 days.
-
Validate wear data then green-light steel production mold.
Useful Links
Final Takeaway
UHMW-PE injection molding delivers unrivalled wear life, impact strength and chemical inertness—now in complex, high-volume geometries that machining can’t match. Partner with TaiwanMoldMaker.com to master the tricky processing window and put ultra-high-wear performance to work on your next industrial project. Upload your files today and receive a no-obligation feasibility study within 48 hours.
