Leverage INTERTECH Injection Molding for High‑Temperature and High‑Strength Requirements

When products must operate in extreme heat, mechanical stress, or chemically aggressive environments, standard commodity plastics simply won’t do. Engineers need advanced materials—PEEK, PPS, Ultem™ (PEI), glass‑fiber PA, and high‑temperature PC blends—processed with tight control and deep tooling expertise. INTERTECH (https://www.taiwanmoldmaker.com) specializes in high‑temperature, high‑strength injection molding, delivering critical components for industries where failure is not an option.

1  Why High‑Performance Polymers?

Polymer Continuous‑Use Temp (°C) Key Strength / Benefit Typical Application
PEEK 240 °C ~140 MPa tensile, chemical & radiation resistance Oil‑&‑gas downhole sensors, aerospace brackets
PPS 200 °C Low creep, inherent flame resistance Automotive turbocharger parts, E/E connectors
PEI (Ultem™) 170 °C High dielectric strength, FDA food contact compliant Medical sterilizable components, aerospace ducts
GF Nylon 6/6 150 °C 30–50 % glass → metal‑like stiffness Under‑hood clips, industrial gear housings

These materials maintain structural integrity well beyond the limits of ABS, PP, or even PC, enabling lightweight metal replacement in harsh settings.

2  Processing Challenges—And INTERTECH Solutions

Challenge INTERTECH Capability
High melt temps (330–400 °C) Electric & hybrid presses to 450 °C barrel temps; shear‑controlled screw designs
Moisture sensitivity (PEI, PA, PPS) In‑line resin dryers & closed‑loop hoppers maintaining < 0.04 % moisture
Tool steel wear (glass & mineral fillers) H13 / S136 hardened steels + nitrided gates & inserts
Warpage / shrink variation Mold‑flow simulation + conformal‑cooled tooling for balanced pack & cool

3  Design Guidelines for High‑Temp Parts

  1. Wall Thickness – Uniform 1.0–3.5 mm minimizes differential cooling stress.

  2. Radii & Fillets – ≥ 0.6 T to reduce notching in fiber‑filled resins.

  3. Draft – 1–2° on polished surfaces to prevent sticking (less on textured).

  4. Boss & Rib Ratios – 0.6–0.75 T avoids sink while preserving load paths.

INTERTECH’s DFM team evaluates every feature for flow, venting, and ejection under elevated mold temperatures (120‑180 °C).

4  Market Applications

Automotive & Mobility

  • Thermostat housings, turbo air ducts → PPS + 40 % GF withstands 200 °C under‑hood.

  • EV power electronics housings → UL 94 V‑0 PEEK for high voltage insulation.

Aerospace & Defense

  • Cabin air diffusers, sensor brackets → Ultem™ & carbon‑fiber PEEK for weight savings and flame compliance (FAR 25.853).

Medical & Lab Equipment

  • Autoclavable handles, surgical instrumentation → PEI retains strength after 1 000 steam cycles.

Oil & Gas / Industrial

  • Sealing rings & pump cages → PEEK handles hot hydrocarbons + high pressure.

5  Why INTERTECH for High‑Performance Molding?

  • 30 + years tooling advanced polymers with press tonnage 50–650 t.

  • ISO 9001 & ISO 13485 quality systems; IATF 16949 support for Tier‑1 automotive.

  • Conformal‑cooled steel molds shorten cycle time on high‑heat materials.

  • Material partnerships with Victrex®, Solvay®, Sabic®, and DSM for rapid sourcing.

  • In‑house metal insert overmolding & secondary machining for critical tolerances.

View case studies on our custom molding page or request a free material‑and‑DFM consultation.

Conclusion

High‑temperature and high‑strength plastic components unlock new possibilities for lightweighting, durability, and cost savings versus metal. INTERTECH combines advanced press technology, specialized tooling steels, and deep material know‑how to deliver reliable parts that thrive where conventional plastics fail.

 Need components that can take the heat? Contact INTERTECH for a tailored quote and project review.
