Discover Flexible Injection-Molded Plastics for a Wide Range of Consumer Applications

From soft-touch grips and living-hinge lids to kid-safe wearables and squeezable dispensers, flexible injection-molded plastics let you deliver comfort, safety, and durability without sacrificing scale or cost. This guide highlights the best elastomer and low-modulus options, key design rules, and a fast path from CAD to shelf with TaiwanMoldMaker.com.

1) The Flexible Materials Playbook

Material Family Feel & Durometer Standout Traits Typical Uses Notes on Overmolding
TPE-SEBS / TPE-S Soft, Shore A 30–90 Dry feel, good UV & skin contact Phone cases, tool grips, stroller parts Bonds well to PP/PE; use mechanical locks on PC/ABS
TPU (Ether/Ester) Rubber-like, A 70–95 Abrasion & tear resistance, clear grades Wearables bands, sports gear, cable boots Dry thoroughly; good to PC/ABS with adhesion grades
TPV (EPDM/PP) A 60–90 Heat/oil resistant, automotive interior friendly Cupholder liners, pedal pads Co-molds to PP best
LDPE / LLDPE Soft, hinge-friendly Stress-crack resistance, squeezable Flip-tops, liner seals, protective trays Ideal for living hinges; gate away from hinge
PP (impact copolymer) Semi-flex, low modulus Lightweight, fatigue-resistant Hinge lids, snap features Works as substrate for TPE overmolds
LSR (Liquid Silicone Rubber) Silky, A 10–70 Biocompatible, heat-sterilizable Baby nipples, medical wearables, kitchen tools Runs in dedicated LSR cells; zero plasticizers

2) Design Rules for Comfortable, Durable Parts

  • Wall thickness: 0.8–2.0 mm for TPE/TPU skins; 0.6–1.2 mm for LDPE hinges.

  • Radii: ≥ 0.5× wall to prevent stress whitening or tearing.

  • Draft: 1.5–3° per side on soft parts; increase under textured surfaces.

  • Living hinges (LDPE/PP): 0.25–0.35 mm at hinge web; polish to SPI-A2 and gate opposite the hinge.

  • Overmold bonding: Combine chemical adhesion grade + mechanical locks (windows/undercuts 0.3–0.6 mm deep).

  • Texture & hygiene: VDI 27–30 masks flow lines yet cleans easily—ideal for cosmetics/OTC and baby products.

3) Processing Windows (get first-shot-right)

  • TPE-SEBS: Melt 190–220 °C; mold 20–40 °C; moderate–high fill to avoid knit-line weakness.

  • TPU: Dry to ≤ 0.02 % moisture; melt 200–220 °C (ether) or 210–230 °C (ester); vent generously.

  • LDPE/LLDPE: Melt 180–200 °C; mold 20–40 °C; holding 40–60 % of peak, 3–5 s.

  • LSR: A/B dosing at 1:1; mold 150–200 °C; cold runner preferred; short cure + post-bake as needed.

4) Consumer Applications That Win with Flex

  • Personal care & beauty: Flip-top caps, lotion pumps, soft jar liners.

  • Wearables & electronics: Watch bands, shock-absorbing bezels, button boots, VR face gaskets.

  • Baby & family: Teethers, pacifiers (LSR), spill-proof lids, stroller grips.

  • Kitchen & home: Heat-safe spatulas (LSR), anti-slip mats, quiet bumpers.

  • Sports & outdoors: Grips, mouthguards (TPU), hydration-pack bite valves.

  • Packaging & closures: Tamper-evident spouts, squeeze-dispense fitments, living-hinge lids.

5) Sustainability & Compliance, Built In

  • Mono-material design: Pair PP substrates with SEBS-TPE overmolds to improve recyclability.

  • PCR & bio-content: Trials available for PCR-LDPE and bio-based TPU.

  • Slimmer cycles, lower CO₂: Conformal-cooled inserts + all-electric presses commonly reach ≤ 0.45 kWh/kg.

  • Regulatory: Food-contact (FDA/EU), phthalate-free grades, REACH/RoHS, and ISO 10993 for skin contact on request.

6) Quick Case Snapshot — Smart Toothbrush Grip

KPI Before (Rigid PC/ABS + glued TPE sleeve) After (2-shot PC/ABS + TPE-SEBS)
Components 3 1
Cycle Time 32 s 23 s
Scrap 3.2 % 0.9 %
Drop Test @ 1.5 m Fail rate 6 % < 1 %
Cost/Unit @ 300 k/yr US $1.18 US $0.96

How TaiwanMoldMaker.com Makes It Friction-Free

  • 48-Hour DFM Pack — gate, cooling, overmold adhesion plan, and cost model.

  • Prototype → Production — aluminum bridge tools (10–15 days to T-0) roll into H13 multi-cavity steel with tool-credit options.

  • Process confidence — scientific molding with cavity-pressure sensors; CpK ≥ 1.67 by the first shift.

  • Finishing & testing — pad print/laser mark, color-match to Delta-E<1.0, pull/peel and torque-shear adhesion tests.

  • Live dashboards — MES access for CpK, OEE, and shipment status.
