WSS-558D Series DC Inverter Ceiling Circulation Fan | Energy Saving HVAC Solution | 600x600mm Grid Fan

Product Overview

The Ultimate Solution for Indoor Air Circulation and Energy Efficiency

The WSS-558D "Wind Fan" series is designed to optimize indoor airflow, reduce air conditioning loads, and provide significant energy savings. Featuring a DC Inverter Motor, this fan saves up to 60% of electricity compared to traditional AC fans. Ideally suited for offices, commercial spaces, and homes, it ensures rapid temperature balancing with 360-degree circulation.

Key Features & Variations

1. High-Efficiency DC Technology

• Energy Saving: Utilizes a DC inverter motor to lower power consumption by approximately 60%, contributing to a greener environment and lower utility bills.

• Eco-Friendly: Certified with the Green Mark and Energy Label.

2. Versatile Model Options

• Standard Remote Control Model (Basic)

  • Features: Comes with a remote control offering 5 wind speeds and 3 timer settings. Includes a memory function to retain settings.

  • Application: Ideal for standard rooms. It works with air conditioning to quickly lower indoor temperatures.

  • Coverage: Recommended installation density is 1 unit per 10-13 square meters (3-4 ping).

• Duct Connection Model (HVAC Integrated)

  • Function: Connects directly to the AC duct to accelerate cold air delivery and circulation throughout the room.

  • Accessories: Comes factory-installed with a 10-inch collar. An 8-inch collar is available as an optional add-on.

  • Benefit: Acts as a booster to push conditioned air effectively, eliminating hot spots.

• Power-On Start Model (Smart Management)

  • Function: Automatically starts when power is supplied. Ideal for centralized control systems where multiple fans are managed by a single wall switch.

  • Customization: Preferred speed (Medium or High) can be set at the factory upon order.

  • Note: Does not include a remote control (cost-effective for B2B). A remote can be purchased separately to adjust functions if needed.

  • Best For: Server rooms, large offices, and public facilities requiring auto-restart after power outages.

• Flagship Black Edition

  • Design: Features a sleek, all-black aesthetic to match modern industrial or dark-ceiling interior designs.

  • Availability: Can be combined with any of the functional variations above (Basic, Duct, or Power-On Start).

3. Installation Flexibility

• Standard Grid: Fits standard 60x60cm ceiling grids (T-Bar).

• Fixed Bracket Accessory (Optional):

  • Application: Allows installation on non-grid ceilings, such as wood or concrete (cement) surfaces.

  • Material: Made from Nylon + Fiber, offering superior strength and durability compared to standard ABS brackets.

Quality & Certifications

We prioritize safety and quality. The WSS-558D series holds multiple rigorous certifications:

• BSMI Safety Certification (R391123).

• Energy Label Certification.

• Green Mark Certification (Eco-friendly).

• 99% Product Yield Rate: Ensuring top-tier reliability.

Technical Specifications
