DC Energy-Saving Ceiling Air Circulator Fan
Model: WSS-558D
The WIND FAN WSS-558D DC Ceiling Circulator Fan is designed to improve indoor air circulation while significantly reducing energy consumption. By working together with air conditioning systems, it helps distribute cool air evenly throughout the space, enhancing cooling efficiency and indoor comfort.
This model is widely used in commercial spaces, offices, retail stores, schools, and residential projects, especially where energy efficiency and stable airflow are required.
Certifications & Compliance
-
BSMI Certified (Safety Compliance)
-
Energy Efficiency Label
-
Environmental Protection Label
-
Designed to meet high standards for safety, energy saving, and durability
Key Applications & Functional Options
1. Standard Version (Remote Control Type)
-
Remote control operation
-
5 fan speed levels
-
3 timer settings
-
Memory function (restores previous settings after power recovery)
-
Works with air conditioners to quickly lower indoor temperature
-
Recommended installation density: 1 unit per 3–4 ping (approx. 10–13 m²)
2. Duct Type Version (Air Duct Connection)
-
Factory-installed 10-inch duct adapter
-
Compatible with 8-inch duct adapter (optional accessory)
-
Can be connected to AC flexible ducts
-
Accelerates cold air circulation and assists air conditioners in air delivery
-
Ideal for commercial and large indoor spaces
3. Power-On Auto Start Function
-
Fan automatically starts when power is supplied
-
Startup speed can be preset at medium or high speed during order confirmation
-
Factory preset before shipment
-
Remote control not included for this function
(Optional remote control available to manage all functions)
4. Flagship Black Version
-
Entire unit finished in full black color
-
Designed for modern and premium interior decoration
-
All functional options available in black version
5. Fixed Mounting Bracket (Optional Accessory)
-
Suitable for non-suspended ceilings such as:
-
Wooden ceilings
-
Concrete ceilings
-
-
Suspended installation method
-
Made of nylon + fiber composite
-
Stronger and more durable than traditional ABS
-
Widely used across various industrial and commercial environments
-
Product Specifications
| Item | Specification |
|---|---|
| Model | WSS-558D |
| Color / Material | Light Gray White / Black / Anti-static ABS |
| Fan Blade Size | 14 inch |
| Air Outlet Size | 16 inch |
| Overall Dimensions | 600 × 600 × 210 mm (Front 110 mm / Rear 100 mm) |
| Weight | 4.4 kg ± 0.5 kg |
| Energy Efficiency | 3.01 Q (m³/min) |
| Total Air Volume | 75.66 Q (m³/min) |
| Power Consumption | 1–5 Speed: 5 / 9 / 14 / 19 / 24 W |
| Noise Level | 1–5 Speed: 12 / 18 / 26 / 33 / 40 dB(A) |
| Airflow Volume | 1–5 Speed: 2221 / 2977 / 3107 / 3901 / 4540 CMH |
Key Advantages for Buyers
-
DC motor for high efficiency and low energy consumption
-
Improves AC performance and reduces overall electricity costs
-
Multiple configuration options for different project requirements
-
Certified safety and environmental compliance
-
Suitable for OEM / bulk procurement / project installation
???? Inquiry & Custom Orders Welcome
Please contact us for OEM options, bulk pricing, accessories, and project solutions.
