Select the Best Plastic for Injection Molding to Optimize Performance & Durability

Choosing the wrong polymer can double scrap rates, trigger field failures, or inflate unit cost. The right choice, on the other hand, balances mechanical strength, chemical resistance, aesthetics, and price—while slotting neatly into your existing tooling and processing window. Use the framework below to pick the optimal resin for any project and avoid expensive mid-program material swaps.

1 | Clarify Your Critical-to-Quality (CTQ) Targets

CTQ Category	Key Questions	Typical Resin Shortlist
Mechanical Load	Static, cyclic, or impact?	PP-GF, PA 66-GF, PEEK-CF
Thermal Range	>120 °C continuous?	PPS, PEEK, PEI
Chemical / UV	Acids, fuels, outdoor?	PP, HDPE, ASA, PVDF
Cosmetics	Piano-black gloss? Clear?	ABS, PC, PMMA
Regulatory	Food, ISO 10993, UL 94 V-0?	PP-Random, PC, PC/ABS-FR

2 | Compare Core Resin Families

Resin Family	Strengths	Limitations	Common Applications
Commodity (PP, HDPE)	Lowest cost, chemical-proof	Lower modulus	Caps, totes, hinges
Engineering (ABS, PC, POM)	Impact, dimensional hold	Mid-range price, drying needed	Enclosures, gears
High-Temp (PEEK, PPS, LCP)	200 °C+, chemical inert	High price, tight processing	Pumps, EV battery, aerospace
Optical (PC, PMMA, COC)	High clarity, polishable	Scratch sensitivity	Lenses, light pipes
Elastomeric (TPE, TPU)	Rubber-like, recyclable	Low structural stiffness	Seals, grips

3 | Tune Properties With Low-Cost Additives

Additive	Adds	Typical Loading	Cost Impact
Glass Fiber	+4-5× tensile	20–30 %	+$0.30–0.50 /kg
Talc / CaCO₃	+Modulus, scratch	10–40 %	+$0.05 /kg
PTFE / MOS₂	Low friction	5–15 %	+$0.20 /kg
UV Stabiliser	Outdoor life	0.5–2 %	Cents/part

4 | Design & Processing Considerations

Shrink & Warp – Semi-crystalline resins (PP, PA) shrink 1–2 %; use Moldflow to pre-offset.
Moisture Sensitivity – Nylon absorbs water; dry at 80 °C > 4 h.
Tool Steel – Glass-filled PPS demands H13; clear PC can live in P20 with polish upgrade.
Cooling Strategy – Conformal inserts pay back fast on thick-wall PC/ABS housings.

5 | Quick-Pick Matrix (Swipe to Match Needs)

Performance Need →	Drop Resistance	High Heat	Chemical	Optical	Budget
Best Fit Resin	PC/ABS-IM, PA66-GF	PPS, PEI	PP-Copo, PVDF	PMMA, PC	Talc-PP, Re-PP

6 | Validation Checklist

Tensile & Izod vs. spec after 2 × regrind loop
Heat-Age 1 000 h @ 120 °C, measure ΔE, modulus
Chemical Soak worst-case media 24 h, 60 °C
UV/Xenon 500 h if outdoor
Dimensional CpK ≥ 1.33 on critical datums post-aging

7 | Leverage Taiwan Mold Maker for Rapid Resin Trials

600+ grades stocked locally—ABS, PC, PP-GF, PEEK, LSR
48-hour DFM & Moldflow with material-specific shrink factors
Prototype-to-Production Credits: aluminum tools offset against H13 steel
On-site labs for QUV, salt-spray, and DSC—accelerated approval

???? Key Service Links

Ready to Match Resin to Performance?

Upload your CAD and CTQ list to TaiwanMoldMaker.com for a material matrix, DFM report, and costed timeline—delivered in just 48 hours—so your next injection-molded part hits both durability targets and budget goals.
